Overview
Memosens sensor for drinking water, pool and process water as well as utilities in all industries.
Specs at a glance
* Measurement range : Trace: 0 to 5 mg/l HOCl
Standard: 0 to 20 mg/l HOCl High: 0 to 200 mg/l HOCl
* Process temperature : 0 to 55 °C (32 to 130 °F), non-freezing
* Process pressure: Max. 1 bar (max. 14.5 psi)
* Measuring method : Closed, membrane covered measuring cell
Reduction of free chlorine at the cathode
* Process temperature : 0 to 55 °C (32 to 130 °F), non-freezing
* Process pressure: Max. 1 bar (max. 14.5 psi)
* Measuring method : Closed, membrane covered measuring cell
Reduction of free chlorine at the cathode
Benefits
* The right sensor version for every application: From trace measurement up to free chlorine concentrations of 200 mg/l.
* Fast response time (t90 < 25 s) provides an accurate process view and enables prompt reaction to process changes as well as efficient process control.
* Increased process safety: precise and long-term stable measurement ensures consistent process monitoring and allows for individually adapted disinfectant dosing.
* The low-maintenance, amperometric sensor reduces the cost of ownership of the measuring point, particularly compared to colorimetric measuring systems.
* More process up-time thanks to fast sensor exchange: pre-calibrate the sensor in your lab and then swap it into your process with plug & play.
* Connection to the Liquiline multiparameter transmitter allows for easy combination with other relevant parameters of liquid analysis such as pH and ORP.
* Fast response time (t90 < 25 s) provides an accurate process view and enables prompt reaction to process changes as well as efficient process control.
* Increased process safety: precise and long-term stable measurement ensures consistent process monitoring and allows for individually adapted disinfectant dosing.
* The low-maintenance, amperometric sensor reduces the cost of ownership of the measuring point, particularly compared to colorimetric measuring systems.
* More process up-time thanks to fast sensor exchange: pre-calibrate the sensor in your lab and then swap it into your process with plug & play.
* Connection to the Liquiline multiparameter transmitter allows for easy combination with other relevant parameters of liquid analysis such as pH and ORP.
Application
Memosens CCS51D is a robust, low-maintenance sensor for free chlorine. It provides high-precision measurement with long-term stability in drinking water, pool and process water and ensures consistent disinfection monitoring even at low water volumes. The
free chlorine sensor features extremely fast response times guaranteeing efficient process control. Memosens CCS51D is not the latest Memosens generation. More information on the new Memosens CCS51E sensor with extended functionality here.
Memosens CCS51D is a free chlorine sensor for skid builders and end customers. It measures reliably in:
* Drinking water - to ensure reliable disinfection
* Process water - for hygienic and safe packaging and bottling of products
* Utilities - to detect the absence or presence of free chlorine
* Pool water - to dose disinfectant efficiently
free chlorine sensor features extremely fast response times guaranteeing efficient process control. Memosens CCS51D is not the latest Memosens generation. More information on the new Memosens CCS51E sensor with extended functionality here.
Memosens CCS51D is a free chlorine sensor for skid builders and end customers. It measures reliably in:
* Drinking water - to ensure reliable disinfection
* Process water - for hygienic and safe packaging and bottling of products
* Utilities - to detect the absence or presence of free chlorine
* Pool water - to dose disinfectant efficiently
![]()
Specification
|
Measuring / Application task
|
Disinfection
|
|
Measuring principle
|
Free chlorine
|
|
Application
|
Ensuring reliable disinfection in drinking water
Process water Dosing disinfectant efficiently in pool water Detect the absence or presence of free chlorine in Utilities Guarantee food safety and provide hygienic packaging and bottling |
|
Characteristic
|
Amperometric measurement of dissolved free chlorine
|
|
Measurement range
|
Trace: 0 to 5 mg/l HOCl
Standard: 0 to 20 mg/l HOCl High: 0 to 200 mg/l HOCl |
|
Measuring method
|
Closed, membrane covered measuring cell
Reduction of free chlorine at the cathode |
|
Design
|
Closed amperometric 2-electrode measuring cell with PVDF membrane
|
|
Material
|
Sensor shaft: POM
Membrane: PVDF Membrane cap: PVDF Sealing ring: FKM |
|
Dimension
|
Diameter: 25 mm (0.98 inch)
Length: 161 mm (6.34 inch |
|
Process temperature
|
0 to 55 °C (32 to 130 °F), non-freezing
|
|
Process pressure
|
Max. 1 bar (max. 14.5 psi)
|
|
Temperature sensor
|
10k NTC integrated (Memosens)
|
|
Connection
|
Inductive, digital connection head with Memosens
|
