VEGA VEGAMAG 81 MLIBridle Level Radar Level Measurement

VEGA VEGAMAG 81 MLIBridle Level Radar Level Measurement

: In stock

: Level Measurement

: VEGA

Sale

Application The VEGAMAG 81 magnetic indicator consists of a bypass, which is mounted as a communicating tube on the side of an existing vessel. The float used in the...

Application


The VEGAMAG 81 magnetic indicator consists of a bypass, which is mounted as a communicating tube on the side of an existing vessel. The float used in the bypass with integrated permanent magnet system transmits the liquid level contactlessly to the magnetic display mounted on the outside of the bypass. Thus, the level of a vessel is displayed on the magnetic indicator without external energy and can be seen from afar.

Specification

item
value
Grade
Industrial
Warranty
1 Year
Customized support
OEM, ODM, OBM
Place of Origin
Germany
Brand Name
VEGA
Model Number
VEGAMAG 81
Measuring range - Distance
4 m [Meter - Foot]
Process temperature
-196 ... 450 °C [°C - °F]
Accuracy
 ± 5 mm / ± 0.2"
Seal material
no media contact
please contact email for more about the shipping cost

We normally ship by DHL, UPS, FEDEX or TNT,

some country could not be ship by above method, then we would use EMS or Country Logistics line.
