Overview
Designed to meet highest levels of demands for enhanced metering in the Food & Beverage industry, HygienicMaster FEH630 delivers more than reliable and accurate measuring values.
This innovative next generation of electromagnetic flowmeters provides a modular transmitter design combined with SmartSensor technology and built-in verification – technical advances that deliver a clear business and performance benefit.
The sensor-design ensures optimum protection from breathing and condensation.
Exchangeable process connections for maximum flexibility, simplified installation and reduce inventory. The sensor is CIP/SIP cleanable, FDA approved and certified in accordance with 3A.
Ethernet IP communication increases operational performance and delivers more real-time data for a better decision making.
HygienicMaster FEH630 is one of the most cost saving flowmeters on the market and ideally suited for all hygienic applications.
HygienicMaster FEH630 – The first choice for all hygienic applications. Advanced features and functionality that enable you to operate more efficiently, reduce costs and increase profitably.
- Real-time diagnostic keep your process up and running
– Detecting critical process conditions at an early stage reduce unscheduled downtime and maintenance
– Clear text messages simplify troubleshooting - In-built noise/grounding check
– Verify the installation is correct from day one
– Checks for proper grounding which is fundamental to an accurate flow measurement - In-built verification for highest confidence in your flow measurement
– Checking for sensor and transmitter Integrity
– No need to remove the flowmeter from the process - Simplicity of operation
– Automatic self-configuration sequence
– Incredibly easy to work with - Ethernet IP communication
– For remote access to built-in diagnostic monitoring the flowmeter and your process
– Flowmeter verification and configuration over Ethernet minimizing commissioning time
– Built-in webserver, no additional software required for flowmeter configuration
Benefits
-
Hygienic Design for Critical Processes
Designed to meet strict hygiene requirements in food, beverage and pharmaceutical applications. -
Reliable Measurement Performance
Provides stable and accurate flow measurement for conductive liquids. -
Reduced Downtime with Advanced Diagnostics
Integrated diagnostics help identify process conditions and prevent unexpected interruptions. -
Easy Cleaning and Maintenance
Supports CIP/SIP cleaning procedures and simplifies maintenance operations. -
Flexible Installation Options
Multiple hygienic process connections allow easy integration into different process systems. -
Improved Process Transparency
Ethernet communication and built-in verification provide better access to measurement data and device status.
Specification
| item | value | |
|---|---|---|
| accuracy | ±0.4% of rate (Optional ±0.3% / ±0.2%) | |
| type | Hygienic Electromagnetic Flowmeter | |
| brand name | ABB | |
| model number | FEH630 | |
| measurement type | Magnetic Inductive Flow Measurement | |
| measurement media | Conductive Liquids | |
| flow measurement | Volume Flow Measurement of Hygienic Liquid Media | |
| measuring principle | Faraday's Law of Electromagnetic Induction | |
| nominal diameter | DN 1 to DN 100 (1/25 to 4 in.) | |
| output signal | Configurable Current Output, Pulse/Frequency Output | |
| communication protocols | HART; PROFIBUS DP; PROFIBUS PA; Modbus RTU; Modbus TCP; Ethernet/IP; PROFINET; Webserver | |
| display | LCD Graphic Display | |
| display technology | Through-The-Glass (TTG) Operation | |
| local operation | Configuration without Opening the Housing via Touch Control / Soft Keys | |
| electronics | Modular Transmitter Design with SmartSensor Technology | |
| transmitter design | Compact Mount Design or Remote Mount Design | |
| diagnostics | Empty Pipe Detection, Gas Bubble Detection, Electrode Impedance Monitoring, Conductivity Monitoring, Sensor Temperature Monitoring | |
| verification function | ABB Ability™ Verification for Measurement Devices | |
| process connection | Weld Stubs, Threaded Pipe Connections, Tri-Clamp, Wafer Type, Flanges and Hygienic Connections | |
| liner material | PFA (Vacuum Stable) | |
| electrode materials | Configuration Dependent | |
| fluid temperature | Up to 180 °C (356 °F) | |
| pressure rating | PN 10 to PN 40; ASME Class 150 / 300 (Configuration Dependent) | |
| protection rating | IP67 / IP68 | |
| certification | 3-A Sanitary Standard; FDA Approved Materials | |
| housing | Configuration Dependent (Compact or Remote Version) | |
| features | SmartSensor Technology, Built-in Verification, Hygienic Design, CIP/SIP Cleaning Capability and Ethernet Connectivity | |
| applications | Food & Beverage, Pharmaceutical and Hygienic Process Industries |
