Endress+Hauser Liquid Analysis Digital Turbidity Sensor CUS52D

Availability: In stock

Product type: Liquid Analyzers

Vendor: Endress+Hauser

Precio habitual ~~$2,200.00~~ $2,200.00 Oferta

Overview Hygienic Memosens sensor for turbidity measurement in drinking water, process water and utilities. Specs at a glance * Measurement range：0.000 to 4000 FNU* Process temperature ...

Precio habitual ~~$2,200.00~~ $2,200.00 Oferta

Cantidad

Details
GLOBAL SHIPPING & DELIVERY

Overview

Hygienic Memosens sensor for turbidity measurement in drinking water, process water and utilities.

Specs at a glance

* Measurement range：0.000 to 4000 FNU
* Process temperature

Stainless steel version: -20 to 85 °C (0 to 185 °F)
Plastic version: -20 to 60°C (-4 to 140 °F)
* Process pressure Stainles steel version: 0.5 to 10 bar abs(7.3 to 145 psi abs)
Plastic version: 0.5 to 6 bar abs (7.3 to 87 psi abs)

Benefits

* Measuring results like in the lab: Highly accurate and reliable monitoring of your water quality – even at the lowest turbidity.
* Turbidity measurement without product loss: Hygienic inline measurement preserves each drop of water in the process.
* Unattended operation: Intelligent design and practical accessories enable sophisticated self-cleaning capabilities and minimize maintenance.
* Smart verification and calibration: Absolutely safe, liquid-free, without Formazin.
* Great flexibility, simple handling: One sensor for all measuring points and all installation environments (inline or immersion).
* Improved process control: Individually adaptable sensor response time.
* Fast commissioning: Factory calibration and Memosens technology allow plug & play integration into your process.

Application

Turbimax CUS52D is a smart sensor with lab accuracy that allows unattended operation of all turbidity measuring points in drinking
water production and many other applications with fresh, process or salt water. You can mount it directly into your pipeline, thus
saving costly bypass installations and avoiding product losses. Thanks to Memosens digital technology, the Turbimax CUS52D offers
maximum process and data integrity, simple operation and allows predictive maintenance.

Turbimax CUS52D measures turbidity in:
* Drinking and process water:
- From inlet to outlet in water plants
- Raw water abstraction and control
- Distribution networks
- All quality control points in water production
* Saline water:
- Desalination plants
- Marine applications (e.g. monitoring of exhaust gas cleaning on ships)
* Wastewater treatment plants:
- Reuse of outlet water (e.g. 4th cleaning step)
* Utilities in all industries:
- From inlet to outlet in water production
- Distribution networks

Specification

Measuring / Application task	Total Solids / Total Suspended Solids
Measuring principle	Single beam scattered light
Application	Turbidity measurement in: Drinking and process water Saline water Utilities of all industries
Installation	Inline Insitu, sensor with clamp, flow cell, sensor with clamp, retractables, sensor straight, immersion in open channels
Design	40 mm sensor
Dimension	40 mm design, hygienic Clamp-version 320 x 40 mm
Material	Stainless steel version: 1.4404 Plastic version: sensor head: PEEK, shaft: PPS Optical windows: sapphire O-rings: EPDM
Measurement range	0.000 to 4000 FNU
Ingress protection	IP68
Output / communication	Memosens

Measuring / Application task	Turbidity
Measuring principle	Single beam scattered light
Application	Turbidity measurement in: Drinking and process water Saline water Utilities of all industries
Installation	Inline Insitu, sensor with clamp, flow cell, sensor with clamp, retractables, sensor straight, immersion in open channels
Measurement range	0.000 to 4000 FNU
Measuring principle	Nephelometric turbidity sensor (90° scattering) according to ISO7027
Design	40 mm sensor
Material	Stainless steel version: 1.4404 Plastic version: sensor head: PEEK, shaft: PPS Optical windows: sapphire O-rings: EPDM
Dimension	40 mm design, hygienic Clamp-version 320 x 40 mm
Process temperature	Stainless steel version: -20 to 85 °C (0 to 185 °F) Plastic version: -20 to 60°C (-4 to 140 °F)
Process pressure	Stainles steel version: 0.5 to 10 bar abs (7.3 to 145 psi abs) Plastic version: 0.5 to 6 bar abs (7.3 to 87 psi abs)
Temperature sensor	Stainless steel version:-20 to 85 °C (0 to 185 °F) Plastic version: -20 to 60°C (-4 to 140 °F)
ngress protection	IP68
Output / communication	Memosens
Additional certifications	ISO 7027
