Overview
Rosemount™ 3300HTVP High Performance pH and ORP Sensor
The Rosemount 3300HTVP High-Performance pH Sensor / ORP Sensor features a robust design that significantly prolongs sensor life in complex applications. The rebuildable pH/ORP sensor works well in high temperature and high pressure processes and resist fouling,coating and poisoning. Compared to other sensor designs, the Rosemount 3300HTVP pH/ORP Sensor decreases the frequency of sensor replacement and provides faster pH/ORP measurement response times and decreased drift.
Benefits
* Increased pH sensor / ORP sensor life and performance in high temperature and high pressure applications up to 155 °C and 400 psig
* SMART preamplifier allows automatic recognition of pH sensors by Rosemount 1066, 1057, 1056 and 56 transmitters
* Selectable reference electrolytes allow sensors to be used in a large number of applications
* Ease of installation with Variopol (VP8) cable connection
* SMART preamplifier allows automatic recognition of pH sensors by Rosemount 1066, 1057, 1056 and 56 transmitters
* Selectable reference electrolytes allow sensors to be used in a large number of applications
* Ease of installation with Variopol (VP8) cable connection
Specification
|
item
|
|
value
|
|
|
Warranty
|
|
1 Year
|
|
|
Customized support
|
|
OEM, ODM, OBM
|
|
|
Place of Origin
|
|
United States
|
|
|
Brand Name
|
|
ROSEMOUNT/EMERSON
|
|
|
Model Number
|
|
3300HTVP
|
|
|
Type
|
|
High Performance pH and ORP Sensor
|
|
|
Battery
|
|
No
|
|
|
Usage
|
|
Industrial, Pen-Type pH Meter
|
|
|
Measurement range
|
pH
|
0 to 14
|
|
|
|
Oxidation reduction potential (ORP)
|
-1500 to +1500 mV
|
|
|
Operating temperature
|
Without preamplifier
|
41 to 311 °F (5 to 155 °C)
|
|
|
|
With preamplifier
|
Up to 212 °F (100 °C)
|
|
|
Storage temperature
|
|
14 to 138 °F (-10 to 70 °C)
|
|
|
Maximum process pressure
|
|
400 psig (2859 kPa
|
|
|
CRN rating
|
CRN rating
|
200 psig at room temperature
|
|
|
Wetted materials
|
|
Platinum (ORP only), titanium, Ryton, PTFE, glass, and user-specified O-ring material (EPDM, FKM, or FFKM)
|
|
|
Reference electrode
|
|
Double junction with replaceable process side electrolyte and PTFE junction
|
|
|
Temperature sensor
|
|
Pt-100 Resistance Temperature Device (RTD)
|
|
|
Process connections Must use 1-in. compressi
|
|
Must use 1-in. compression process connector (PN 23166-00 or 23166-01)
|
|
|
Cable length
|
|
4 to 15 ft. (1.2 to 4.6 m) integral cable (Rosemount 3300HT) or VP8 cable for Rosemount 3300HTVP (sold separately)
|
|
|
Weight/shipping weight
|
|
1 lb./2 lb. (0.5 kg/0.9 kg)
|
|
